Fiberglass reinforced mesh disc
Payment Type: L/C,T/T
Port: NINGBO SHANGHAI
Material: Aluminum Oxide Ceramic Alumina/Aluminum Oxide
Size: customize
Option: 240; 120
- Overview
- Recommended Products
| Warranty: | 3 Years |
| Customized Support: | Oem |
| Place Of Origin: | Zhejiang, China |
| Brand Name: | GRAND |
| Model Number: | fiberglass disc |
| Type: | Abrasive Disc |
| Application: | Cutting disc |
| Shape: | Round Disc |
| Yarn Type: | E-glass |
| Color: | Brown,Black,etc. |
| Selling Units : | piece |
| Package Type : | Strong Carton Packing |
| Picture Example : |  |
Product Description
Fiberglass reinforced mesh disc for grinding wheel is cut by puncher from reinforcing netlike fiberglass cloth for grinding wheel. The cloth was coated with phenolic resin or epoxy resin, and then baked. It has two types. One type is nets coated with adhesive bonded fabric and with black paper. The other type is pure net. The net is widely used as the basal material of grinding wheel which adopts resin as adhesive agent. The grinding wheel made of this basal material has properties of excellent heat resistance, strong structural strength, and cutting at high speed and great structural strength.
Our regular sizes of fiberglass cloth for reinforced net is CNG5x5mm-260g/m2，CNG6x6mm-190 g/m2，CNP8x8mm-260g/m2,CNG14×14-85g/m2; Outer diameter of the fiberglass disc isΦ74±1,Φ96±1，Φ122±1，Φ146±1，Φ196±1，Φ246±1，Φ296±1，Φ346±1，Φ396±1mm,etc, inner diameter isΦ17±0.5, Φ23±0.5, Φ26±0.5, Φ33±0.5mm, etc., other sizes are all available.
VOLATILES:
| VOLATILESCONTENT(%) | INSOLUBLES CONTENT(%) | RESIN CONTENT(%) | OUTSIDE DIAMETER(mm) | INSIDE DIAMETER(MM) | STRENGTH CN/TEX |
| ≤10 | ≤10 | 26~36 | ф70～ф800±1.5 | ф10～ф60±1 | ≥38 |
We produce grinding wheel mesh has more than 20 years of history, exported all over the world, we supply for a famous big manufacturer of grinding wheel in Europe, the quality is widely recognized by customers.
