High-Quality Molded Frp Grating – Durable, Corrosion-Resistant Solutions for Industrial Applications
Molded FRP grating is made of glass fibre braiding, the unsaturated polyester resin (including Ortho resin, lso resin, Vinyl resin and Phenolic resin, etc.) fully saturated a thermosetting molding in the metal mould. lt is composed of several symmetrical grids, firm structure and mechanical properties with two-ways gay.
Explore the superior performance of our High-Quality Pultruded FRP Profile, a premium composite solution engineered for demanding environments where traditional materials fail.GRAND FRP are large producer and exporter of Fiberglass products and FRP grating and FRP pultruded profile in China . We have own brand GRAND FRP to sale in all world market.We have ISO9001: 2000 certificate, IQ net, USA SGS test and USA ABS certificate.
Our leading products: FRP molded grating, pultruded grating, Pultruded profiles, etc. FRP grating have excellent ability: corrosion and chemical resistance, fire resistant, light weight, no slip, high strength, long service life. specifications of molded grating: FRP pultruded profiles: Standard structural shapes include equal angle, l beam, Wide flange beam, square tube, round tube, kick plate etc. These structural shapes are used in a wide range of applications, offering a unique combination of chemical resistance, size stability, high strength, and thermal, electric non-conductivity. Each shape is available in a number of dimensions to suit for a variety of design and application requirements. For special uses, custom shapes are also available. Orthophthalic resin, lsophthalic resin and vinyl ester resin are available, as per different environments.
Different resin for different applications: Qualified raw materials ensure the excellent quality of FRP grating.All raw materials are fromcarefully selected advanced suppliers.
| Resin System | |||
| Resin Base | Resin Type | Description | Application |
| Orthophthalicpolyester resin | Type O | Moderate corrosion resistanceand fireretardant, flame spread ratingASTM E84Class1,25 or Less operationtemperature-50℃~100℃ | such grating are perfect for use inwater/wa stewater or air-a gingapplications light industrialapplications, and in the wave zoneareas of offshore platforms where the.environment is moderate.Although Type O isthe least chemical resistant resin.it stilloffers superior performance to traditionalflooring products such as steel,aluminum andwood and is the most economical resin available |
| IsophthalicPolyester | Type l | Industrial grade corrosionresistance andfire retardant, flame spread ratingASTME84 Class1, 25 or Less operationtemperature-50℃~105℃ | Such grating can be used inthe environments of middleconcentration inorganicacid, inorganic alkali, etc |
| Vinyl ester | Type V | Superior corrosion resistanceand fireretardant flame spread ratingASTM E84Class 1,25 or less operationtemperature-50℃~110℃ | Such grating can be used inthe environments withserious corrosion |
| Food gradepolyester resin | Type F | Food grade corrosion resistanceand fireretardant operationtemperature-50℃~105℃ | Such gratings are often usedn food Plants or drinkingwater Plants |
| Phenolic resin | Type P | resistance flame spreadrating ASTM E84 Class 1,5 orless, smoke developed indexo, operation temperatureamountingto 180℃ | Such grating are used in areaswhere fire resistance,lowsmoke and low toxic fumes arecritical |
| High flameresistant viny.ester | Type HV | Superior corrosion resistanceand enhancedfire retardant flame spread ratingASTM E84Class 1,10 or less operationtemperature-50℃-110C.Such grating has passedassessmentfrom ABS(American Bureau ofShipping) | Such grating can be used inthe environments with seiouscorrosion requiring betterflame resistance |
Standard structural shapes include equal angle，I beam，Wide flange beam，square tube，round,tube.kick plate etc.These structural shapes are used in a wide range of applications,offering a unique combination of chemical resistance，size stability，high strength，and thermal,electric non-conductivity.Each shape is available in a number of dimensions to suit for a variety of design and application requirements.For special uses.custom-Shapes are also available. OrthophthaIic resin，lsophthalic resin and vinyl ester resin are available，as per different environments.
