We use the German Dornier high-grade rapier loom, German Karl Mayer warper sizing machine, beaming machine, 4.6m automatic sectional warping machine, 3.4m air jet looms,, etc.. They are all top class in the world. With these machines, we produce variety kinds of fiberglass fabrics: leno weave, plain weave, twill weave, satin weave, mesh which are made by the singlees or doubling (G37, G75, G150, B150, BC150, E225, E110, D450, D900) fiberglass. Their maximum width can reach 4.4m.

The thickness ranges from 0.05mm to 1.2mm, and the weight ranges from 24g/m2 to 2000g/m2. The fabrics is suitable for PTFE, PVA, PU and silica gel coating.

Our products mainly include base fabric for membrane materials, PTFE, PVC, PE, PU, silica gel, conveyor belt and FRP(Fiberglass Reinforce Plastic). They can be used in curtains, structural membrane materials, conveyor belts, projection screens, advertising cloths, light box cloths, shade cloths, filter cloths, soft ceilings, sports apparatus and yacht, etc.

Specification	Yam Type(Warp × Weft)	Warp/weft density (roots/cm)	Thickness(mm)	Weight(g/m²)	Width(m)
2116	E225 1/0 IZ / E225 1/0 IZ	23.6/23.2	0.095	105	0.9-3.4
128-1(J)	E225 1/3 3.8S / E225 1/3 3.8S	16.8/12.8	0.175	200	0.9-3.4
128-2(J)	G150 1/2 3.8S / G150 1/2 3.8S	16.8/12.8	0.175	200	0.9-3.4
7628	G75 1/0 0.7Z / G75 1/0 0.7Z	17.3/13	0.18	210	0.9-3.4
7628T	G150 1/2 2.5S / G75 1/0 0.7Z	17.3/13	0.18	210	0.9-3.4
7628TT(1528)	G150 1/2 2.5S / G150 1/2 2.5S	17.3/13	0.18	210	0.9-4.2
5430T	G150 1/2 2.5S / G75 1/0 0.7Z	17.3/13	0.17	180	0.9-3.4
7630	G150 1/2 2.5S / G67 1/0 0.7Z	17.3/13	0.21	220	0.9-3.4
7638	G75 1/0 0.7Z / G37 1/0 0.7Z	17.3/10	0.26	255	0.9-3.4
7638T	G150 1/2 2.5S / G75 1/2 2.75S	17.3/10	0.26	255	0.9-3.4
7508	G150 1/2 2.5S / G75 1/0 0.7Z	8/14/	0.15	255	0.9-3.4
141	G75 1/2 2.75S / G75 1/2 2.75S	12.5/8.5	0.28	285	0.9-3.4
141A	G75 1/2 2.75S / G37 1/0 0.7Z	12.6/8.2	0.28	285	0.9-3.4
7513	G150 1/2 2.5S / G75 1/0 0.7Z	9/10	0.14	130	0.9-3.4
513	G150 1/2 0.7Z / G37 1/0 0.7Z	9/9	0.2	183	0.9-3.4
	G150 1/0 0.7Z / G75 1/0 0.7Z	16/9.6	0.12		0.9-3.4
	G150 1/0 0.7Z / G75 1/0 0.7Z	8/16	0.12	112	0.9-3.4
713	G75 1/2 2.5S / G37 1/0 0.7Z	9/9	0.26	255	0.9-3.4
3228	G75 1/0 0.7Z / G75 1/0 0.7Z	12.5/11	0.12	160	0.9-3.4
3020	G150 1/2 2.5S / G37 1/0 0.7Z T5	12/8	0.2	195	0.9-3.4
3020	G150 1/2 2.5S / G37 1/0 0.7Z T5	12/8	0.2	195	0.9-3.4
3228T	G150 1/0 0.7Z / G75 1/0 0.7Z	12.5/11	0.12	160	0.9-3.4
7620	G150 1/2 2.5S / G75 1/0 2.75S	17.3/12	0.2	200	0.9-3.4
7632	G150 1/2 2.5S / G75 1/0 0.7Z	17.3/13.5	0.2	210	0.9-3.4
532	G150 1/2 2.5S / G37 1/0 0.7Z	17.3/13.2	0.26	300	0.9-3.4
7528	G75 1/2 2.75S / G37 1/0 0.7Z	45944	0.28	330	0.9-3.4
7581	G75 1/0 0.7Z / G37 1/0 0.7Z	57/54/in	0.24	300	0.9-3.4
5426(J)	G75 1/2 2.75S / G37 1/0 0.7Z	45883	0.26	300	0.9-3.4
H250	G75 1/2 2.75S / G75 1/2 2.75S	13/8.4	0.25	291	0.9-4.2
H250(J)	G150 2/2 3.8S / G150 2/2 3.8S	12.8/8.4	0.25	290	0.9-4.2
7530	G75 1/2 2.75S / G75 1/2 2.75S	46004	0.3	340	0.9-4.2
7533	G75 1/2 2.75S / G75 1/3 2.75S	12/8.5	0.33	340	0.9-4.2
0.34#(J)	DE75 1/3 3.3S / DE75 1/3 3.3S	24.5/21 (25)	0.34	370
0.45#(J)	DE75 2/2 3.8S / DE75 2/2 3.8S	24.5/19.5 (25)	0.45	500
0.4(J)	BC150 4/2 3.8S / BC150 4/2 3.8S	24.5/19.5 (25)	0.45	500	3.3/4.2
7534(H350)	G75 1/3 2.75S / G75 1/3 2.75S	10/8.2	0.34	370	0.9-3.55
3732	G37 1/0 0.7Z / G37 1/0 0.7Z	17.3/14	0.4	430	0.9-3.55
3732T	G75 1/2 2.75S / G37 1/0 0.7Z	17.3/14	0.4	430	0.9-3.55
3730	G37 1/2 2.75S / G37 1/3 2.75S	5*2/7	0.6	560	0.9-3.55
3740	G37 1/2 2.75S /G37 1/2 2.75S	17.3/14	0.4	430	0.9-3.55
EPC500	G75 1/3 2.75S /G75 1/3 2.75S	17/7.8	0.46	505	0.9-3.55
EPC500(J)	G150 1/6 1.5S /G150 1/6 1.5S	16/8.4	0.46	500	0.9-3.55
3750	G37 1/3 2.75S /G37 1/2 2.75S	8/8	0.5	550	0.9-3.55
3755	G37 1/3 2.75S /G37 1/3 2.75S	8/7	0.55	630	0.9-3.55
3760	G37 1/3 2.75S /G37 1/4 2.75S	45876	0.55	750	0.9-3.55
3770	G37 1/4 2.75S /G37 1/4 2.75S	8/5.2	0.6	744	0.9-3.55
690	G37 1/3 2.75S /G37 1/3 2.75S	9/8	0.65	690	0.9-3.55
3770A	G37 1/3 2.75S /G37 1/5 2.75S	45906	0.8	820	0.9-3.55
3775	G37 1/3 2.75S /G37 1/5 2.75S	45875	0.7	730	0.9-3.55
3783	G37 1/0 0.7Z /G37 1/0 0.7Z	21/19	0.48	556	0.9-3.55
3784	G37 1/4 2.75S /G37 1/5 2.75S	45875	0.8	850	0.9-3.55
3784A	G37 1/3 2.75S /G37 1/2 2.75S	15/15	0.55	800	0.9-3.55
3786A	G37 1/3 2.75S /G37 1/3 2.75S	15/15	1.2	1200	0.9-3.55
3788A	G37 1/4 2.75S /G37 1/5 2.75S	15/15	1.5	850	0.9-3.55
3788	G37 1/4 2.75S /G37 1/4 2.75S	18/13.2	1.6	1700	0.9-3.55
3788B	G37 1/4 2.75S /G37 1/4 2.75S	18/14.2	1.65	1750	0.9-3.55
0620A	G75 1/3 2.75S /H25 1/0 0.7Z	15/15	0.45	620	0.9-3.55
620	G75 1/3 2.75S /G75 1/3 2.75S	15/15	0.45	620	0.9-3.55
06/55	G75 1/3 2.75S/G37 1/2 2.75S	11/6.5	0.55	405	0.9-3.55
EWF600A	12.534 / 12.534	20/20	0.6	600	0.9-3.55
EW360	300Tex / 300Tex	45814	0.36	360	0.9-3.55
EW360A	300Tex / 300Tex	45814	0.38	360	0.9-3.55
EW300	200Tex / 200Tex	45876	0.3	300	0.9-3.55
EW300A	200Tex / 200Tex	45876	0.3	300	0.9-3.55

We offer reasonable prices and excellent services and have established long-term partnerships with a lot of enterprises. We warmly welcome you to visit us and make business negotiations.
